Los materiales utilizados para la fabricación de los tubos de calderas de acero carbono resistentes a la corrosión
Product Description Product Ttem Grade Chemical composition C Si Mn P.≤ S.≤ Cr Ni others Carbon steel 1 10 0.07/0.13 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.15 ≤0.30 Cu≤0.25 2 20 0.17/0.23 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.25 ≤0.30 Cu≤0.25 3 A179 0.06/0.18 - 0.27/0.63 0.03 0.03 - - - 4 A192 0.06/0.18 ≤0.25 0.27/0.63 0.03 0.03 - - - Boiler steel tubes are generally made of high-grade carbon steel and alloy steel, which meet ASME standards, and it is designed for use in boilers,
-
Tubos de caldera sin costuras de acero carbono de alta calidad resistentes a la corrosión
Product Description Tube Sizes for Heat Exchangers & Condensers & Boiler Outside Diameter BWG 25 22 20 18 16 14 12 10 Wall Thickness mm 0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40 mm inch Weight kg/m 6.35 1/4 0.081 0.109 0.133 0.174 0.212 9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429 12.7 1/2 0.214 0.263 0.356 0.457 0.612 0.754 15.88 5/8 0.271 0.334 0.455 0.588 0.796 0.995 19.05 3/4 0.327 0.405 0.553 0.729 0.895 1.236 25.4 1 0.44 0.546 0.75 0.981 1.234 1.574 2.05 31.75 1 1/4 0
-
Tubos de caldera de acero carbono de alta calidad con excelente resistencia a la corrosión
Product Description Chemical&Mechanical parameters Grade C Mn Si Cr Mo S P 20G 0.17~0.23 0.35~0.65 0.17~0.37 --- --- ≤0.020 ≤0.025 20MnG 0.17~0.23 0.70~1.00 0.17~0.37 --- --- ≤0.020 ≤0.025 25MnG 0.22~0.29 0.70~1.00 0.17~0.37 --- --- ≤0.020 ≤0.025 12CrMoG 0.08~0.15 0.40~0.70 0.17~0.37 0.40~0.70 0.40~0.55 ≤0.020 ≤0.025 15CrMoG 0.12~0.18 0.40~0.70 0.17~0.37 0.80~1.10 0.40~0.55 ≤0.020 ≤0.025 SA-210A1 ≤0.27 ≤0.93 ≥0.10 --- --- ≤0.035 ≤0.035 SA-210C ≤0.35 0.29~1.06 ≥0.10 --- --- ≤0
-
Tubos de caldera de acero de cabón pintados de alta calidad para la pared de la membrana de la caldera
Product Description Product Ttem Grade Chemical composition C Si Mn P.≤ S.≤ Cr Ni others Carbon steel 1 10 0.07/0.13 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.15 ≤0.30 Cu≤0.25 2 20 0.17/0.23 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.25 ≤0.30 Cu≤0.25 3 A179 0.06/0.18 - 0.27/0.63 0.03 0.03 - - - 4 A192 0.06/0.18 ≤0.25 0.27/0.63 0.03 0.03 - - - Boiler steel pipe is a kind of steel pipe made of boiler-grade materials, among which, carbon steel pipe can be divided into seamless steel pipe, straight
-
ASTM A192 Tubos de caldera sin costuras de acero carbono de alta calidad para centrales eléctricas
Product Description Standard: ASTM A192/SA192SMLS Size:(mm) Out Dimensions: 12.7mm – 114.3mm Wall Thickness: 0.8mm - 15mm Length: Fixed(6m,9m,12,24m) or normal length(5-12m) Product Ttem Grade Chemical composition C Si Mn P.≤ S.≤ Cr Ni others Carbon steel 1 10 0.07/0.13 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.15 ≤0.30 Cu≤0.25 2 20 0.17/0.23 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.25 ≤0.30 Cu≤0.25 3 A179 0.06/0.18 - 0.27/0.63 0.03 0.03 - - - 4 A192 0.06/0.18 ≤0.25 0.27/0.63 0.03 0.03 - - -
-
Tubos de caldera de acero de carbono de alta calidad para aplicaciones de alta presión y temperatura
Product Description HDT Boiler Steel Tube is a great choice for high-pressure and temperature applications. It is made with high-quality carbon steel and comes with a MOQ of 10 tons. It is corrosion resistant and provides a smooth surface finish. With a competitive price and an assurance of delivery, this product is sure to be a perfect fit for any industry. Product Ttem Grade Chemical composition C Si Mn P.≤ S.≤ Cr Ni others Carbon steel 1 10 0.07/0.13 0.17/0.37 0.35/0.65 0
-
Tubos de acero al carbono resistentes a altas temperaturas utilizados en calderas Normas ASME
Product Description Product Ttem Grade Chemical composition C Si Mn P.≤ S.≤ Cr Ni others Carbon steel 1 10 0.07/0.13 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.15 ≤0.30 Cu≤0.25 2 20 0.17/0.23 0.17/0.37 0.35/0.65 0.03 0.03 ≤0.25 ≤0.30 Cu≤0.25 3 A179 0.06/0.18 - 0.27/0.63 0.03 0.03 - - - 4 A192 0.06/0.18 ≤0.25 0.27/0.63 0.03 0.03 - - - Boiler steel tubes are generally designed for use in boilers, pressure vessels, and heat exchangers. It is made of boiler-grade materials, usually made of
-
Tubos de acero carbono/acero inoxidable/acero aleado utilizados en calderas Normas ASME
Product Description Grade 321 321H 1.4541 UNS Designation S32100 S32109 Carbon (C) Max. 0.08 0.04–0.10 0.08 Manganese (Mn) Max. 2.00 2.00 2.00 Phosphorous (P) Max. 0.045 0.045 0.040 Sulphur (S) Max. 0.03 0.03 0.015 Silicon (Si) Max. 1.00 1.00 1.00 Chromium (Cr) 17.0–20.0 17.0–20.0 17.0-19.0 Nickel (Ni) 9.0–12.0 9.0–12.0 9.0–12.0 Molybdenum (Mo) — — Nitrogen (N) – – Iron (Fe) Bal. Bal. Bal. Other Elements Ti=5(C+N) to 0.70% Ti=4(C+N) to 0.70% Ti=5(C+N) to 0.70% Boiler steel
