Erw soldó con autógena los tubos de caldera de acero del codo que Sch Std Sch80 reduce el tipo inconsútil
Product Details
| Material: | WPB, WPC, WPHY 42, WPHY 46, WPHY52, WPHY 56, WPHY 60, WPHY 65, WPHY 70, WPHY 80 | Uso: | caldera, energía, producto petroquímico, explotación minera, comida, papel, gas e industria flúida |
|---|---|---|---|
| OD: | 1/4" a 100” Sch10s a XXS | Superficie: | Negro u otro color cubierto |
| Resaltar |
codo de acero a dos caras,codo de la tubería de acero del carbono |
||
Product Description
Las colocaciones de acero de SCH STD SCH80 REDUCEN el CODO Seamless/ERW/Welded
Información de productos:
Tamaño: 1/8" NOTA A 100 " NOTA
Horario: SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Tipo: Inconsútil/ERW/soldado con autógena/fabricó /Forged
Forma: Reductor excéntrico, reductor concéntrico
Materiales
Reductor de acero inoxidable - reductor de los SS
ASTM A403 WP GR. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Reductor de acero de carbono - reductor del CS
ASTM A 234 WPB, WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 Y WPHY 70.
Reductor del acero de carbono de la baja temperatura - reductor de LTCS
ASTM A420 WPL3/A420WPL6
Reductor del acero de aleación - COMO reductor
ASTM/ASME A/SA 234 GR. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Reductor de acero a dos caras
ASTM A 815 UNS NINGÚN S 31803, S 32205.
Reductor de la aleación de níquel
Estándar
- SB 336 DE ASTM/DE ASME.
- UNS 10276 (reductor de HASTELLOY C 276)
- UNS 2200 (reductor del NÍQUEL 200),
- UNS 2201 (reductor del NÍQUEL 201),
- UNS 4400 (reductor de MONEL 400),
- UNS 8020 (reductor de la ALEACIÓN 20),
- UNS 8825 (reductor de INCONEL 825),
- UNS 6600 (reductor de INCONEL 600),
- UNS 6601 (reductor de INCONEL 601),
- UNS 6625 (reductor de INCONEL 625),
Servicios de valor añadido
- Inmersión caliente que galvaniza
- Capa de epoxy
Certificado de prueba
Certificado de prueba del molino según EN 10204/3.1B
El caber de la tubería de acero del carbono - reducción de codos
ASME/ANSI B16.9
Estándar
| Tamaño nominal del tubo | Centro a terminar | Peso en libras |
| 2 x 1 | 3 | 1,2 |
| 2 x 1 1/4 | 3 | 1,3 |
| 2 x 1 1/2 | 3 | 1,4 |
| 2 1/2 x 1 1/4 | 3,75 | 2,5 |
| 2 1/2 x 1 1/2 | 3,75 | 2,6 |
| 2 1/2 x 2 | 3,75 | 2,8 |
| 3 x 1 1/2 | 4,5 | 3,3 |
| 3 x 2 | 4,5 | 3,6 |
| 3 x 2 1/2 | 4,5 | 4,2 |
| 3 1/2 x 2 | 5,25 | 4,5 |
| 3 1/2 x 2 1/2 | 5,25 | 5,5 |
| 3 1/2 x 3 | 5,25 | 6 |
| 4 x 2 | 6 | 6 |
| 4 x 2 1/2 | 6 | 6,8 |
| 4 x 3 | 6 | 7,7 |
| 4 x 3 1/2 | 6 | 8,4 |
| 5 x 2 1/2 | 7,5 | 10,7 |
| 5 x 3 | 7,5 | 11,8 |
| 5 x 3 1/2 | 7,5 | 12,6 |
| 5 x 4 | 7,5 | 13,4 |
| 6 x 3 | 9 | 16,8 |
| 6 x 3 1/2 | 9 | 17,8 |
| 6 x 4 | 9 | 18,9 |
| 6 x 5 | 9 | 21 |
| 8 x 4 | 12 | 33,1 |
| 8 x 5 | 12 | 36,2 |
| 8 x 6 | 12 | 39,7 |
| 10 x 5 | 15 | 58,5 |
| 10 x 6 | 15 | 63,2 |
| 10 x 8 | 15 | 73 |
| 12 x 6 | 18 | 86,5 |
| 12 x 8 | 18 | 98,4 |
| 12 x 10 | 18 | 113 |
Estándar
| Tamaño nominal del tubo | Centro a terminar | Peso en libras |
| 2 x 1 | 3 | 1,7 |
| 2 x 1 1/4 | 3 | 1,8 |
| 2 x 1 1/2 | 3 | 1,9 |
| 2 1/2 x 1 1/4 | 3,75 | 2,9 |
| 2 1/2 x 1 1/2 | 3,75 | 3 |
| 2 1/2 x 2 | 3,75 | 3,4 |
| 3 x 1 1/2 | 4,5 | 4,5 |
| 3 x 2 | 4,5 | 4,9 |
| 3 x 2 1/2 | 4,5 | 5,7 |
| 3 1/2 x 2 | 5,25 | 6,4 |
| 3 1/2 x 2 1/2 | 5,25 | 7,3 |
| 3 1/2 x 3 | 5,25 | 8,2 |
| 4 x 2 | 6 | 8,4 |
| 4 x 2 1/2 | 6 | 9,4 |
| 4 x 3 | 6 | 10,5 |
| 4 x 3 1/2 | 6 | 11,4 |
| 5 x 2 1/2 | 7,5 | 15,1 |
| 5 x 3 | 7,5 | 16,5 |
| 5 x 3 1/2 | 7,5 | 17,4 |
| 5 x 4 | 7,5 | 18,8 |
| 6 x 3 | 9 | 24,9 |
| 6 x 3 1/2 | 9 | 26,3 |
| 6 x 4 | 9 | 27,9 |
| 6 x 5 | 9 | 31,4 |
| 8 x 4 | 12 | 49,5 |
| 8 x 5 | 12 | 54,3 |
| 8 x 6 | 12 | 60,8 |
| 10 x 5 | 15 | 78,5 |
| 10 x 6 | 15 | 86,5 |
| 10 x 8 | 15 | 102 |
| 12 x 6 | 18 | 114 |
| 12 x 8 | 18 | 132 |
| 12 x 10 | 18 | 148 |
Certificación
