Grueso inoxidable en frío o laminado en caliente 6 - 80m m Q235 Q345 B C D E de la placa de acero
Product Details
| Nombre de producto: | placa de acero de aleación | Estándar: | AISI, ASTM, BS, ESTRUENDO, JIS |
|---|---|---|---|
| Uso: | Placa de la nave | Técnica: | laminado/laminado en caliente |
| Resaltar |
placa del recipiente del reactor,Placa de acero de la nave |
||
Product Description
Q235 Q345 B C D E laminó/el grueso laminado en caliente 6 - 80m m de la placa de acero de aleación
Q345B/C/D/E
1)Estándar: GB
2)Grueso: 6-80m m
3)Anchura: 1600-3200m m
4)Longitud: 6000-14000m m
5)) precio bajo de alta calidad
Componente químico (% peso)
| C | Si | Manganeso | P | S | V | NOTA | Al | Ti | |
| Q345A | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.045 | ≤0.045 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345B | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.040 | ≤0.040 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345C | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.035 | ≤0.035 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345D | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.030 | ≤0.030 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345E | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.025 | ≤0.025 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
Properities mecánico
| grueso | pruebe la temperatura (°c) | Alargamiento (%) | tensión de prueba (Mpa) | Strenth extensible (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
Nuestros productos
| Serie de productos | Estándar ejecutivo | Grado | Clase | Grueso (milímetros) |
Entrega Estado |
| Acero estructural poco aleado | GB/T 1591-2008GB/T 3274-2007 | Q345 | A, B | 6~150 | AR |
| C, D | 6~150 | CR | |||
| E | 6~150 | TMCP | |||
| Q390 | A, B, C, D, E | 6~150 | CR | ||
| Q420 | 6~150 | TMCP | |||
| Q500 | 6~100 | TMCP | |||
| Q550 | 6~100 | ||||
| Q620 | 6~80 | ||||
| Q690 | 6~80 | ||||
| GB/T 28410-2012 | Q235FT | B, C, D, E | 5~150 | AR, CR | |
| Q275FT | C, D, E, F | 5~150 | AR, CR | ||
| Q345FT | C, D, E, F | 5~150 | AR, CR | ||
| Q420FT | C, D, E, F | 5~150 | AR, CR | ||
| Q460FT | C, D, E, F | 5~150 | AR, CR | ||
| 10025-4:2004 del EN | S275M/ML | - | 6~60 | TMCP | |
| S355M/ML | |||||
| S420M/ML | |||||
| S460M/ML | |||||
| JIS G3106: 2008 |
SM400 SM490 |
A, B, C | 6~150 | AR | |
| A, B, C | 6~150 | CR | |||
| YA, YB | |||||
| SM520 | B, C | 6~80 | TMCP | ||
| SM570 | 6~80 | ||||
| ASTM A572/A572M-12 | Gr42 | - | 6~150 | AR | |
| Gr50 | - | 6~100 | CR | ||
| Gr55 | - | 6~100 | |||
| Gr60 | - | 6~80 |
TMCP |
Product Highlights
Q235 Q345 B C D E laminó/el grueso laminado en caliente 6 - 80m m de la placa de acero de aleación Q345B/C/D/E 1)Estándar: GB 2)Grueso: 6-80m m 3)Anchura: 1600-3200m m 4)Longitud: 6000-14000m m 5)) precio bajo de alta calidad Componente químico (% peso) C Si Manganeso P S V NOTA Al Ti Q345A ≤0.20 ≤0...
