ASTM A53 API Carbon Steel Seamless Tube GB5310 para las tuberías de calefacción
Product Details
| Nombre de producto: | Tubo de caldera | Estándar: | GB5310 chino |
|---|---|---|---|
| Uso: | calefacción-tuberías, envases, sobrecalentadores de los dispositivos del carbón-ahorro y recalentado | Grado principal de la tubería de acero: | 20G、 12Cr1MoVG del、 12Cr2MoG del、 15CrMoG del、 15MoG del、 25MnG |
| Resaltar |
API Carbon Steel Seamless Tube,Tubo inconsútil de ASTM A53,Tubo inconsútil de acero de carbono GB5310 |
||
Product Description
Tubo inconsútil de acero de carbono de ASME/tubo estándar ASTM A53 API 5L GrB A106 GrB
Detalles del producto
| Producto | Fabricante inconsútil de las tuberías de acero de la precisión del dibujo frío |
| Material | Acero de carbono y acero de aleación |
| Estándar | JIS3445, DIN2391, EN10305-1, GB/T3639 |
| Grado |
STKM11A, STKM12B, STKM13A, STK400, E235, ST37.4, ST35.8, ST44, ST45, E255, CK45, S45C, AISI4130, AISI4135, AISI4140 |
| Certificado | ISO9001 |
| Tecnología | Laminado y retirado a frío |
| Uso |
Ampliamente utilizado en el coche, automóviles, motocicletas, resortes de gas, maquinaria hidráulica, industria de la maquinaria y de la refrigeración de construcción. |
| Paquete | Abrigo en paquetes con los bolsos tejidos plásticos |
| Términos comerciales | T/T, L/C |
| Situación de la fuente | BK, BKS, BKW, NBK, GBK
|
| Plazo de expedición | A tiempo |
Compositon químico y Propertise mecánico:
| Estándar | Grado | Composición química (%) | ||||||
| C | Manganeso | Si | V | Cr | MES | P.S | ||
| GB5310 | 20G | 0.17~0.24 | 035~0.65 | 0.17~0.37 | / | / | / | ≤ 0,030 |
| 25MnG | 0.22~0.30 | 0.70~1.00 | 0.17~0.37 | / | / | / | ≤ 0,030 | |
| 15MoG | 0.12~0.20 | 0.40~0.80 | 0.17~0.37 | / | / | 0.25~0.35 | ≤ 0,030 | |
| 15CrMoG | 0.12~0.18 | 0.40~0.70 | 0.17~0.37 | / | 0.80~1.10 | 0.40~0.55 | ≤ 0,030 | |
| 12Cr2MoG | 0.08~0.15 | 0.40~0.70 | ≤ 0,50 | / | 2.00~2.50 | 0.90~1.20 | ≤ 0,030 | |
| 12Cr1MoVG | 0.08~0.15 | 0.40~0.70 | 0.17~0.37 | 0.15~0.30 | 0.90~1.20 | 0.25~0.35 | ≤ 0,030 | |
| Propertise mecánico | Resistencia a la tensión (Mpa) | Fuerza de producción (Mpa) | Alargamiento (%) | |||||
| 20G | 410~550 | ≥ 245 | ≥ 24 | |||||
| 25MnG | ≥ 415 | ≥ 240 | ≥ 22 | |||||
| 15MoG | 450~600 | ≥ 270 | ≥ 22 | |||||
| 15CrMoG | 440~640 | ≥ 235 | ≥ 21 | |||||
| 12Cr2MoG | 450~600 | ≥ 280 | ≥ 20 | |||||
| 12Cr1MoVG | 470~640 | ≥ 255 | ≥ 21 | |||||
Product Highlights
Tubo inconsútil de acero de carbono de ASME/tubo estándar ASTM A53 API 5L GrB A106 GrB Detalles del producto Producto Fabricante inconsútil de las tuberías de acero de la precisión del dibujo frío Material Acero de carbono y acero de aleación Estándar JIS3445, DIN2391, EN10305-1, GB/T3639 Grado ...
